Function generators are incredibly handy in a wide range of applications, from RF to embedded logic. Usually, they can be quite pricey, but we've found an affordable solution - the FG085 MiniDDS Function Generator Kit. This 'some assembly required' kit turns into a flexible, functional, and user - friendly frequency generator. Simply solder the through - hole parts, attach the face and base plates, and soon you'll be generating sinewaves up to 200KHz! The FG085 has three operating modes, allowing it to generate 7 types of continuous waveforms, as well as servo test and control signals with micro - second resolution. Its LCD screen and menu system make it a breeze to operate. You can set frequency, amplitude, and offsets using the number pad and fine - tune them with the rotary encoder. You can even adjust the incremental step size for wide - range sweeps. It can generate a peak - to - peak amplitude up to 10V with an offset from - 5 to + 5VDC. Set the amplitude to 0, and it doubles as an adjustable DC voltage source.
Using the FG085 MiniDDS Frequency Generator Kit is easy. First, assemble the kit by soldering the through - hole parts and attaching the face and base plates. Once assembled, you can start using it. To set the frequency, amplitude, and offsets, use the number pad on the instrument. You can then make small adjustments with the rotary encoder. When making wide - range sweeps, adjust the incremental step size for better control. For different types of waveforms and servo signals, switch between the three operating modes. Remember, when handling the kit during assembly, be careful with the soldering iron to avoid burns. Also, make sure all connections are secure. To maintain the generator, keep it in a dry and clean place. Avoid exposing it to extreme temperatures or moisture. If you're not using it for a long time, turn it off and store it properly.
