Product Details
The LIS331HH is an amazing ultra - low - power, high - precision triple - axis linear accelerometer. It offers 16 - bit data output, allowing for highly accurate measurements. You can easily select from full scales of ±6g, ±12g, or ±24g according to your needs. With output data frequencies ranging from 0.5Hz to 1kHz, it can measure accelerations effectively. Its power consumption is incredibly low, as little as 10μA, which is a huge plus for battery - powered devices. This device comes with two programmable independent interrupt engines. They can recognize specific inertial events, adding a lot of fun and flexibility to its use. The board is a perfect fit for applications like navigation, smart agriculture, robotic technology, and VR/AR.Features: Selectable scale ranges of ±6g/±12g/±24g, two programmable interrupts, a smart sleep - to - wake - up function for advanced power saving, and 16 - bit data output.Specifications: Operating Voltage is 3.3V. Operating Current is 10μA - 140μA in low - power mode and 0.3mA - 0.4mA in normal mode. It supports I2C/SPI interfaces with a default I2C Address of 0x19 and a selectable one of 0x18. The frequency range is 0.5Hz - 1KHz. It can operate in temperatures from - 40°C to +85°C, has 10000g high shock survivability, is ECOPACK® RoHS and “Green” compliant, and has dimensions of 15*20 (mm) or 0.59*0.79”.Documents: Product wiki.Shipping List: One Fermion LIS331HH Triple Axis Accelerometer (Breakout) and two 2.54 - 4P Black Single Row Pin Headers.
Using this Fermion I2C LIS331HH triple - axis accelerometer is quite straightforward. First, connect it to your device using the I2C or SPI interface according to your setup. Make sure the operating voltage is set to 3.3V. You can select the scale range that suits your project from ±6g, ±12g, or ±24g. When it comes to power, you can take advantage of the low - power mode to save battery life. Just use the smart sleep - to - wake - up function. There are two programmable interrupts that you can set up to recognize specific events. This can add a lot of functionality to your project. As for maintenance, keep it in a dry and clean environment. Avoid exposing it to high shocks that exceed its 10000g shock survivability. Also, make sure the operating temperature stays between - 40°C and +85°C. If you need more detailed information, refer to the product wiki.
