FeatherS3 - ESP32-S3 Development Board by Unexpected Maker

Discover the FeatherS3, a professional ESP32 - S3 development board in the convenient Feather format. It comes pre - loaded with the latest CircuitPython version supporting ESP32 - S3 and the UF2 bootloader. This makes updating to the latest CircuitPython firmware a breeze - just plug it into your computer and it shows up as a USB flash drive. You can copy or edit your code right on the drive, making microcontroller coding incredibly easy. As new CircuitPython versions are released, you can update from circuitpython.org. You can also use Arduino 2.0.3 or later, and there are ESP - IDF and an early MicroPython port available. Check the TinyS3 product page for more details. The FeatherS3 boasts amazing features like a 32 - bit dual - core 240MHz processor, a RISC - V ultra - low - power core, 2.4GHz Wi - Fi, Bluetooth 5, 16MB QSPI Flash, 8MB extra QSPI PSRAM, USB - C connector, and more. It has reverse USB back - feed protection, 2x 700mA 3.3V LDO regulators, ultra - low deep - sleep current, 2x STEMMA connectors, a low - power RGB LED, and is compatible with FeatherWings.

Using the FeatherS3 is simple. First, plug it into your computer via the USB - C connector. It will appear as a USB flash drive in your filesystem. You can then copy your code over or edit it directly on the drive. When using CircuitPython, update to the latest version from circuitpython.org as needed. For Arduino, make sure to use version 2.0.3 or later. Remember to handle the board with care to avoid any physical damage. Keep it in a dry and clean environment. When charging the LiPo battery, monitor the power and charge LEDs. If you notice any unusual behavior, disconnect the power source immediately. Regularly check for software updates to keep your FeatherS3 performing at its best.
