CurieCore intel® Curie Neuron Module

CurieCore is likely the last publicly available Intel Curie - based development product on the market. It's specifically designed for professional developers and enthusiasts building on Curie's foundation. Intel Curie is a great product, and its core strength lies in the built - in 128 neuron nodes, which bring a new level of smart functionality and endless possibilities to embedded and lightweight sensor nodes. This module integrates onboard Bluetooth 4.0, a 32Mhz Quark processor, and a 6 - Axis accelerometer sensor, making it the smartest chip among same - sized modules. It's the smallest Curie module around, with a minimized size design and an onboard antenna. This makes it ideal for wearable, robotic, and Maker projects while still offering sufficient processing power. Note: Due to Intel Curie's high requirements for storage conditions, each order has a minimum order quantity (MOQ) of 100 pieces. Features: Minimized size, onboard Bluetooth and 6 - Axis accelerometer, comes with a shield, and is tailored for pros. Specification: Chip Module - Intel Curie, Communication Frequency - 2.4 GHz, Operating Voltage - 2.97 ~ 3.63 V, 15 Digital pins and 6 Analog pins (4 - way PWM), I/O Current Drive Capability - 2 ~ 8mA, supports Bluetooth 4.0, chip frequency 32 MHz, supports Arduino Development Platform, Bootloader - Arduino / Genuino 101, Size - 13.6 * 18.3 * 3.1 mm/ 0.53 * 0.72 * 0.12 inches. Documents: Product WIKI, More Documents

Using the CurieCore module is straightforward. First, if you're new to this, make sure you have basic knowledge of the Arduino Development Platform as it's supported by this module. Connect it to your project according to the pin - out details provided in the specification. The module has 15 digital pins and 6 analog pins, including 4 - way PWM, so you can use them to connect different sensors or devices. For communication, the onboard Bluetooth 4.0 allows you to pair it with other Bluetooth - enabled devices easily. Keep in mind the storage conditions. Since Intel Curie has high requirements for the storage environment, store it in a dry and cool place. And don't forget about the minimum order quantity of 100 pieces per order. When it comes to maintenance, avoid exposing it to extreme temperatures or humidity. If you need more information, refer to the Product WIKI and other available documents.
