10 Segment LED Bar Graph - Yellow

These 10-segment yellow LED bar graphs are incredibly versatile. With a small footprint and easy hookup, they're perfect for both prototyping and finished products. In essence, they consist of 10 individual yellow LEDs grouped together, each with its own anode and cathode connection. We also offer these bar graphs in red, blue, and green. Note that the pinout on these bar graphs might differ from what's in the datasheet. Rotating the device 180 degrees will fix this, making pin 11 the first pin. We've informed our supplier to correct this in the future. You can access the datasheet and a YouTube video demo for more details.

Using this 10-segment yellow LED bar graph is easy. First, connect it according to the pinout, though remember it might be different from the datasheet. If you face issues, just rotate the device 180 degrees. You can use it in your prototypes to quickly test your ideas or integrate it into finished products. We also have the same bar graph in red, blue, and green if you need different colors. When it comes to maintenance, keep it in a dry and clean place. If you have any questions, refer to the datasheet or watch the YouTube video demo.
